The DTHC Series: a high-efficiency condensing heating solution.
A condensing heating solution for industrial applications, designed to maximize energy efficiency. Ideal for reducing operating costs and improving overall performance.
Superior Efficiency. Lasting Performance.
Airflow
3,030 to 31,250 CFM
Net capacity
390 to 1,690 MBH
Temperature rise
50 to 120°F
Max LAT
Max 120°F
Optimized energy performance
Condensing technology that recovers heat from combustion gases. Significantly reduces energy consumption and operating costs.
Precise control and advanced modulation
Advanced modulation allows output to be adjusted with precision. Ensures consistent thermal stability and efficient energy management.
Designed for modern ventilation systems
Robust design adapted to demanding environments and modern systems. Integrates easily into air handling units to maximize overall performance and as a duct heater.
- High-efficiency condensing heat exchanger
- Minimum efficiency of 90% (up to ~98% under optimal conditions)
- Heating capacity from 390 to 1,690 MBH
- Airflow from 3,030 to 31,250 CFM
- High-precision modulating system (up to 31:1)
- Temperature rise from 50°F to 120°F
- 304L stainless steel heat exchanger
- Operates on natural gas or propane
- Indoor or outdoor installation
- Designed for integration into an air handling unit
- Horizontal or vertical discharge configuration
- Positive-pressure installation downstream of the fan
- Condensate management system with integrated drains
- Precise temperature control via duct-mounted sensors
- Compatible with high-airflow and continuous-duty applications
- Compliant with CSA and ANSI standards
A solution tailored to your energy goals
In environments where energy efficiency is essential, the DTHC Series offers a high-performance, durable solution. It adapts to your installations to optimize performance while reducing your energy footprint.
